hot chambor die casting machine

20T full-automatic PC hot chamber die casting machine applies broadly to hardware,telecommunication,electricity,toy,rigid machine and other industries. This machine is the product of refinement of other alike products.Its elements of electricity and hydraulic pressure are mostly imports with high quality,and its computer system is imported from Omlon of Japan which is characteristic of high reliability,high production efficiency and high automatizaition.This machine especially fits die-casting different shapes of slide fastener and ironware metals. Characteristics: >auto die-casting with high speed >high speed together with low speed >auto adjusting hydraulic pressure and auto button with oil motor >free choice of fusion heating or oil heating >free choice of generally electronic control or PLC control of machine tool. ITEM UNIT 12T 20T CLAMPING UNIT LOCKING FORCE kN 120 225 CLOSING STROKE mm 120 150 EJECTOR FORCE kN 11 16 EJECTOR STROKE mm 30 35 DIE HEIGHT MINMAX mm 120-200 130-280 SPACE BETEWWWN TIE BARS mm 208*198 233*218 TIE BARS DIAMETER mm 32 42 INJECTION UNIT CASTING FORCE kN 19.7 30.9 CASTING STROKE mm 70 80 TRAVERES STROKE mm 180 240 INJETION PLUNGER DLAMETER mm 32 38 SHOT WEIGHT kg 0.315 0.507 MAX CASTING AREA cm2 50 82 WORKING PRESSURE Mpa 7 7 INJCECTION PRESSURE Kg/cm2 245 272 DRIVING MOTOR kW 4 5.5 DRY CYCLE TIME s 3.5 4 CRUCLBLE CAPACITY kg 70 130 FUEL OIL Kg/h 1.5 2.0 ELECTRIC FURNACE kw 8 11 TANK CAPACITY L 150 180 WEIGHT OF MACHINE kg 1200 1600 OVERALL DIEENSION mm 2200*750 *1700 2300*850*1700
